Product Name:
Window Screen Mesh/Mosquito Screen Mesh, epoxy coated wire mesh, hydraulic filter protective mesh, filter element supporting mesh.
Brief Introduction
Window Screen Mesh/Mosquito Screen Mesh is a high quality window screen designed for home and commercial use, providing superior ventilation while preventing insects and other small animals from entering the interior. The window screen adopts advanced weaving technology, and the mesh is uniform and fine, which can effectively prevent mosquitoes at the same time, without affecting the indoor lighting and vision. Its beautiful design is suitable for various types of Windows, including sliding Windows, casement Windows and sliding Windows, to meet the needs of different users.
Material:
Stainless Steel
Aluminum Alloy
Fiberglass
Nylon
Fiberglass
Specifications:
Wire Diameter: Various sizes available, typically ranging from BWG31 to BWG34.
Mesh Sizes: Common mesh sizes include 14x14, 16x14, 16x16, 18x16, 18x18, 18x14.
Size: Available in a range of sizes to fit windows of various dimensions.
Color: Usually available in silver or can be customized.
|
Product name |
Window Screen Mesh/ Mosquito Screen Mesh |
|
Material |
high-quality stainless steel wire |
|
Weave Type |
Plain weave |
|
Mesh |
17x13 18x14 22x20 |
|
Wire Diameter |
0.2mm |
|
Color |
white, gray, black or customized |
|
Width |
50mm(2 inches)-1500mm(60 inches) |
|
Length |
30m(100ft)-300m(860ft) |
|
Usage |
used as window screen mesh/ mosquito screen mesh |
Product Technical Parameters:
|
Main Specification of the Window Screen |
|||
|
Substrate material |
Specification |
Width |
Length |
|
ASH2011 |
20x18x0.11H |
0.61, 0.71, 0.76, 0.81, 0.91, 1.01, 1.12, 1.22, 1.32, 1.42, 1.52, 1.62, 1.83, 2.13, 2.43, 2.54, 2.64m |
10-30m |
|
ASH2411 |
24x22x0.11H |
10-30m |
|
Product features
(1)Even and square hole
(2)Not easy to loosen and deform, the supporting force is strengthened
(3)Soft mesh surface and easy to be shaped.
(4)Different colors of powder can be coated.
(5)Even and consistent color.
Product advantage
Corrosion Resistance: Stainless steel and aluminum options are ideal for high humidity areas or coastal regions.
High Visibility: Many of our screens are designed to maintain an unobstructed view while keeping insects at bay.
Durability: Fiberglass and nylon options are known for their strength and durability.
Ventilation: All our mesh options provide good airflow, ensuring a comfortable indoor environment.
Product application
Residential and Commercial Buildings: Suitable for both types of buildings to prevent insects from entering.
High-Risk Areas: Flame-retardant coated stainless steel is perfect for areas where fire safety is a concern.
Industrial and Agricultural Settings: Galvanized steel options are great for these settings due to their strength and affordability.
High-End Applications: Bronze and copper options provide an elegant and traditional look for high-end residential and historical buildings.
Installation:
Our Window Screen Mesh is easy to install:
Prepare the Frame: Ensure the window frame is clean and free of any obstructions.
Attach the Mesh: Secure the mesh to the frame using appropriate fasteners or adhesives.
Trim if Necessary: If needed, trim the mesh to fit the exact dimensions of the window.
Maintenance:
Regular Cleaning: Periodically clean the mesh to maintain airflow and visibility.
Inspect and Repair: Check the mesh for signs of wear or damage and address any issues promptly.
Packing
